220V Lithium Ion IDC Distributed Power System 2700W UPS Power Supply
-
High Light
IDC DPS distributed power system
,Lithium ion IDC distributed power system
,UPS Power Supply 2700W
-
PhaseSingle Phase
-
ApplicationNetworking,Access Control
-
ProtectionShort Circuit,Overcurrent,overload/overshort/discharge/charge/short Circuit
-
Output Voltage220V
-
BatteryLithium-ion Battery
-
MaterialMetal Rack Cabinet
-
Place of OriginChina
-
Brand NameCONSNANT
-
CertificationCE
-
Model NumberDPS-1103A
-
Minimum Order Quantity10 pieces
-
Packaging Detailscarton box
-
Delivery Time5-8 working days
-
Payment TermsL/C, T/T
-
Supply Ability500 pieces per month
220V Lithium Ion IDC Distributed Power System 2700W UPS Power Supply
lithium IDC DPS, Lithium-ion IDC DPS, distributed power system
Application of Rack Mount UPS
- Workstations
- data centers
- IT sector
- Networking sector
- Home appliances
- Medical sector,Traffic sector
- Education sector
- Industrial sector
- Telecom sector
- Financial sectororkstations
Power range: 1KVA – 10KVA (1PH/1PH)
Performance characteristics
☆ Intelligent detection, battery type optional, output shunt timing control
☆ Reliable, intelligent, and fast deployment
Modular design, rapid deployment on demand;
Simplify data center planning and design;
Compatible with T2/T3/T4 level in the same data center;
Intelligent detection of running time of fans and capacitors;
Dual 220VAC input, dual 220VAC output, can intelligently detect the power of other equipment (optional).
☆ Effective use of space and load-bearing
The weight of the equipment is equivalent to that of the server, and the weight-bearing only needs 500Kg/m2;
The deployment does not require independent distributed power system space and battery room, and the number of effective cabinets has increased by more than 40%;
Technical parameter
| Model | DPS-1103A | DPS-1106A | DPS-1110A |
| Capacity | 3000VA / 2700W | 6000VA / 5400W | 10000VA / 9000W |
| Input | |||
| Input voltage | 220VAC | ||
| Voltage Range | 176-250Vac @ (80-100%) load | ||
| Frequency Range | 46Hz - 54Hz @ 50Hz system; 56Hz - 64Hz @ 60Hz system | ||
| Power Factor | ≧ 0.99 | ||
| Output | |||
| Output voltage | 208/220/230/240VAC | ||
| Voltage accuracy | ±1% (battery mode) | ||
| Frequency range | 46Hz - 54Hz @ 50Hz system; 56Hz - 64Hz @ 60Hz system (Synchronization range) | ||
| Frequency range | 50Hz±0.1Hz or 60Hz±0.1Hz(battery mode) | ||
| Power factor | ≧ 0.9 | ||
| Crest factor | 3:1 Max. | ||
| Harmonic distortion | ≦2% @ 100% linear load; ≦3% @ 100% non-linear load | ||
| Transfer time | 0 ms (AC mode); 0 ms (Inverter Mode); ﹤10 ms (Inverter ECO) | ||
| Run | |||
| Input and output | 1 line input & 2 lines output or 2 lines input & 2 lines output | ||
| Efficiency | |||
| Inverter Mode | ﹥ 94% | ||
| Battery | |||
| Battery type | 192/230V lithium battery | ||
| Battery capacity | 10AH/12AH/15AH/18AH/20AH/25AH/30AH | ||
| Appearance | |||
|
Dimension D × W × H (mm) |
800 ×438 ×88(2U) Power Host 800 ×438 ×176(4U)/264(6U) include the lithium battery |
||
| Net Weight (kg) | 28 (power host) | ||
| Environment | |||
| Storage temperature | -25 ℃ - 55 ℃ | ||
| Working temperature | 0 ℃ - 45 ℃ | ||
| Working altitude | ﹤ 2000 m | ||
| Working humidity | ﹤95% No condensation | ||
| Working noise | ﹤55dB @ 1 meter distance | ||
| Management | |||
| Intelligent slot | Support Window@2000/2003/XP/Vista/2008,Window @7/8, Linux and MAC | ||
| Optional | Support SNMP CARD | ||
＊ The output efficiency will be reduced to 60% when CVCF mode;
＊ The output power will be reduced to 90% when the output voltage is set to 208VAC.
