RS232 Interface Rack Mounted Ups Systems 6KVA , 220V Single Phase Smart Ups 1500 Rack Mount

RS232 Interface Rack Mounted Ups Systems 6KVA , 220V Single Phase Smart Ups 1500 Rack Mount

Products - Rack Mount Power Supply
  • Highlight

    server rack battery backup

    ,

    rack mount ups power supply

  • Capacity
    6KVA
  • Phase
    1ph/1ph
  • Waveform
    Pure Sine Wave
  • Output Volt. Accuracy
    220V±1%(steady-state Load),220V±3%(load Fluctuations)
  • Output Frequency
    50/60Hz±0.05Hz(battery Power)
  • Bettery Charger Current
    4A/8A Optional
  • Place of Origin
    Shenzhen
  • Brand Name
    CONSNANT
  • Certification
    ICE, ISO
  • Model Number
    CNG111RT
  • Minimum Order Quantity
    10
  • Price
    Negotiable
  • Packaging Details
    Export Standard Package
  • Delivery Time
    21 days
  • Payment Terms
    T/T, L/C
  • Supply Ability
    1000 pieces

RS232 Interface Rack Mounted Ups Systems 6KVA , 220V Single Phase Smart Ups 1500 Rack Mount

  • RS232 Interface Rack Mounted Ups Systems 6KVA , 220V Single Phase Smart Ups 1500 Rack Mount
Get Price Contact Now

RS232 Interface Rack Mount Power Supply With External SNMP Adapter 6KVA






Key Features:



  • Double-conversion online High reliability design



  • Good load protection ability( Machine the internal standard matches the output isolation transformer, anti-interference ability)




  • Environment adaptable: Wide voltage input range up to 304V-456V, avoid frequently switching to battery power supply, adapting to the power environment in poor areas. Wide input frequency range of UPS, generators can be guaranteed access to a variety of fuel oil stability.





  •  Intelligent battery management technology optimize high-performance battery





  • Network Management humanity: English / Chinese (optional) LCD display panel help user accurately display the working environment and UPS status information, user-friendly operation of the UPS.



  • Through RS232 interface and intelligent monitor software to communicate with the computer, and the various parameters of UPS can be clear displayed on the communications interface.





  • External SNMP adapter, UPS with remote network: management capabilities, providing real-time UPS date and power information through variety of network operating system for communication and management.




Technical Specifications:



Model CNG111
Capacity 6KVA
Rated Voltage 220V single phase
Rated Frequency 50/60Hz
AC Input
Voltage Range 220V±25%single phase
Frequency Range 50/60Hz±5%
Soft Start 0-100% 5sec
Power Factor >0.92(with input filter)
Bypass Input
Voltage Range 220V±25% single phase
Frequency Range 50/60Hz±10%
Inverter Bypass (overload) 0ms
Output
Voltage Accuracy 220V±1%(steady-state load),220V±3%(load fluctuations)
Frequency Accuracy 50/60Hz±0.05Hz(battery power)
Power Factor 0.8(lagging)
Distortion <3%(linear load ), <5%(non linear load )
Steady-state Response Time <10ms
Overload Capacity 110%load can run normally; 125%10min;150%1min
Battery
Nominal Voltage 192V
Float Voltage 216V
Shut-off Voltage 168V
Charger Current 4A/8A optional
Other
Display LEDLCD
Alarm Sound and light alarm
Protection UPS over current,short circuit,under voltage,over temperature
Environment
Noise 60-65dB
Operating Temperature : 0-40ºC Relative humidity : 0-90%
Box Color Gray(optional)





RS232 Interface Rack Mounted Ups Systems 6KVA , 220V Single Phase Smart Ups 1500 Rack Mount 0
