High Light
330W Outdoor Emergency Power Supply
,QC3.0 Outdoor Emergency Power Supply
,MPPT Portable Rechargeable Energy System
-
Charging ModeAdapt Charging/ Solar Charging
-
Remained Energy RateRemained Energy Rated From 0% To 100%, The Cycle Ring Changes With SOC.
-
LIGHT-ASlightly Bright 2W.
-
Discharge Temperature-10℃~50℃
-
Battery TypeLithium Ion Battery
-
E7 Voltage LowBattery Voltage Is Too Low, Stop Discharging And Allow Charging
-
Place of OriginShenzhen,China
-
Brand NameCONSNANT
-
CertificationCE,ISO9001/ISO14001
-
Model NumberCPET-MP 330W
-
Minimum Order Quantity1 Unit
-
PriceNegotiable
-
Packaging DetailsWooden case
-
Delivery Time20 days after receiving 30% deposit
-
Payment TermsL/C, T/T, Western Union
-
Supply Ability500 pieces per month
QC3.0 330W Outdoor Emergency Power Supply Portable CPET-MP MPPT
Portable Outdoor Emergency Power Supply
USB output
Long press USB Key One Seconds, on USB Output function, the blue backlight of the key lights up, and the corresponding area of the display screen displays“ USB-A USB-C ”Icon, indicating USB-A Common port and quick filling port USB-Type C Quick charge port output. Long press One Seconds off USB Output function, long press Three Seconds to turn off all output functions.
Car charging
When the vehicle is started, connecting wire is used to connect the vehicle lighter and the input port. The display lights up and flashes "CHG ->" to indicate charging, and the input shows charging power, indicating that the ring color block of electric quantity flashes, input voltage between 12V to15V.
Solar charging
Insert the output terminal of the solar energy into the input port of the device, and the display flashes "CHG- >" to indicate charging, while the input displays the charging power, indicating that the ring color block of the power is flashing. It is suitable for solar photovoltaic panels with output voltage in the range of 18V-25V, and supports 120W charging at most. MPPT maximum power tracking technology is adopted to charge the solar photovoltaic panels with maximum output capacity in case of power fluctuation. The output power of solar energy is greatly affected by light, and the fluctuation of output power is a normal phenomenon.
Specifications
| Rated power | 200W |
| Rated capacity | 288.6wh |
| Standard capacity | 3.7V78000mAh |
| Overload protection | 360±20W |
| AC output | 240V±10%/50HZ |
| Output waveform | Sine Wave |
| USB output | QC3.0/18W |
| Type-C output | QC3.0/18W |
| Cigarret lighter output | 12V/10A |
| DC 5521 output | 12V/5A |
| Wireless charging | 5W |
| Charging input Voltage | 12-24V |
| Working temperature | -10-40℃ |
| Weight(Net weight) | ≈3.3kg |
| Weight(with accessories) | ≈4.3kg |
| Dimension | 205*155*165mm |
The product cannot be discharged
① It cannot be output and the display screen does not light up when any key is pressed. Please contact the after-sales service.
② The backlight of the key and the display are on when the key was pressed, but there is not output in the corresponding area. Check whether the equipment connection is normal. If the connection is normal, check whether the alarm code is prompted to output the overload protection. Restart and try again after removing the responsibility.
③ Check whether the rated power of the electrical equipment is greater than the maximum limited power, and do not use if it exceeds the limited value.
Stop working during product use① Check whether the power supply is too low, check the power of the display screen and confirm the alarm code. If the power is too low, please charge in time.
② Check whether the power supply has overload, high temperature, low temperature, short circuit and other abnormal conditions. Check the alarm code of the display screen. If there are corresponding abnormal conditions, please deal with them according to different alarms in the alarm table.
After-sales service
During the use of the product, the normal operation according to the user's manual can not eliminate the fault. Please contact the dealer in time and give clear feedback to the after-sales personnel: product model, purchase date, contact number and fault phenomenon.
① Product warranty period 1 year
The shelf life is calculated from the date of purchase by consumers. In order to determine the purchase date, consumers are requested to keep the purchase related bills and online purchase records.
② During the warranty period, the company shall undertake the obligation of free maintenance and parts replacement for defects caused by product process or materials and damage caused by non-human factors.
③ The following are not covered by the warranty.
• Dismantle and repair without permission of non-staff
• Product performance failure due to human factors
• Damage caused by natural disasters, lightning, accidents and other irresistible factors
• Appearance damage after use is not covered by warranty
