Portable Outdoor Emergency Power Supply
Long press USB Key One Seconds, on USB Output function, the blue backlight of the key lights up, and the corresponding area of the display screen displays“ USB-A USB-C ”Icon, indicating USB-A Common port and quick filling port USB-Type C Quick charge port output. Long press One Seconds off USB Output function, long press Three Seconds to turn off all output functions.
Long press the DC button for 1 second to turn on the DC output function. The blue backlight of the button lights up. The corresponding area of the display screen displays the "DC CIG" icon, indicating the output of cigarette lighter port. Long press for 1 second to turn off DC output function, and long press for 3 seconds to turn off all output functions.
When the vehicle is started, connecting wire is used to connect the vehicle lighter and the input port. The display lights up and flashes "CHG ->" to indicate charging, and the input shows charging power, indicating that the ring color block of electric quantity flashes, input voltage between 12V to15V.
Insert the output terminal of the solar energy into the input port of the device, and the display flashes "CHG- >" to indicate charging, while the input displays the charging power, indicating that the ring color block of the power is flashing. It is suitable for solar photovoltaic panels with output voltage in the range of 18V-25V, and supports 120W charging at most. MPPT maximum power tracking technology is adopted to charge the solar photovoltaic panels with maximum output capacity in case of power fluctuation. The output power of solar energy is greatly affected by light, and the fluctuation of output power is a normal phenomenon.
|Cigarret lighter output
|DC 5521 output
|Charging input Voltage
Stop working during product use
① Check whether the power supply is too low, check the power of the display screen and confirm the alarm code. If the power is too low, please charge in time.
② Check whether the power supply has overload, high temperature, low temperature, short circuit and other abnormal conditions. Check the alarm code of the display screen. If there are corresponding abnormal conditions, please deal with them according to different alarms in the alarm table.
During the use of the product, the normal operation according to the user's manual can not eliminate the fault. Please contact the dealer in time and give clear feedback to the after-sales personnel: product model, purchase date, contact number and fault phenomenon.
① Product warranty period 1 year
The shelf life is calculated from the date of purchase by consumers. In order to determine the purchase date, consumers are requested to keep the purchase related bills and online purchase records.
② During the warranty period, the company shall undertake the obligation of free maintenance and parts replacement for defects caused by product process or materials and damage caused by non-human factors.
③ The following are not covered by the warranty.
• Dismantle and repair without permission of non-staff
• Product performance failure due to human factors
• Damage caused by natural disasters, lightning, accidents and other irresistible factors
• Appearance damage after use is not covered by warranty
