LFP 7.5KWH Power Storage Systems PV Module 2 MPPT For Home

LFP 7.5KWH Power Storage Systems PV Module 2 MPPT For Home

  • High Light

    LFP Power Storage System


    7.5KWH Power Storage System


    2 MPPT Battery Backup System

  • Storage Capacity
  • Battery Type
  • Module Design
    7.5KWH Per Module
  • Ambient Temperature Rate
  • Module Dimensions (W × H × D)
  • Warrant Inverter
  • Place of Origin
  • Brand Name
    Home Energy Storage System
  • Certification
  • Model Number
  • Minimum Order Quantity
    2 Unit
  • Price
  • Packaging Details
    Export Standard Package
  • Delivery Time
    Two weeks
  • Payment Terms
    T/T, L/C
  • Supply Ability
    200 set per month

LFP 7.5KWH Power Storage Systems PV Module 2 MPPT For Home

Storage Capacity 15KWH Energy Storage System Smaller Size Better For Home Use


Description :


This energy storage system can provide power to connected loads by utilizing PV power,
utility power and battery power and store surplus energy generated from PV solar
modules for use when needed. When the sun has set, energy demand is high, or there is
a black-out, you can use the energy stored in this system to meet your energy needs at
no extra cost. In addition, this energy storage system helps you pursue the goal of
energy self-consumption and ultimately energy-independence.
Depending on different power situations, this energy storage system is designed to
generate continuous power from PV solar modules (solar panels), battery, and the utility.
When MPP input voltage of PV modules is within acceptable range (see specification for
the details), this energy storage system is able to generate power to feed the grid (utility)
and charge. This energy storage system is only compatible with PV module types of
single crystalline and poly crystalline. Do not connect any PV array types other than
these two types of PV modules to the energy storage system. Do not connect the
positive or negative terminal of the solar panel to the ground. See Figure 1 for a simple
diagram of a typical energy storage system.
AC input and output                                                                                                                                             DC input
Norminal AC input powe                               5000W                                                                                            Max.PV input power                         6500W

Norminal AC output power                           5000W                                                                                             Max.PV input voltage                       370V

Max. AC output Apparent power                   6000VA                                                                                             Startup voltage                                150V

Max. AC output current                                        /                                                                                                     MPPT voltage range                       100-500V

Norminal output voltage                                220VAC                                                                                             No. of MPPT                                      2
Battery input and output


Battery voltage range                                 42-57V

Nominal battery voltage                             51.2V

Max.charging current                                 80A
Max.discharging current                           150A

Dimension(W × H × D)



The Home Ess electrical inter face provides a simple connection to any home or bulding.It is revolutionary compact
design achieves market-leading energy density and is easy to install.enabling owners to quickly realize the benefits
of reliable,clean power.
