CNS 1-3K 240VAC 3KVA Ups With Lithium Battery ISO9001

 Feature:



Zero Transfer time

True Double Conversion Online UPS, provide most comprehensive protect mission critical equipment from wide range power quality issues



DSP Digital Control Based

Advance DSP base digital control bring high performance of high input Power factor, low distortion , supply the load with perfect sine wave AC power supply



Li-ion Battery Powered

Provide up to 3x backup time in 50% dimension, comparing with regular Lead-acid UPS product

Li-ion Battery Charger

Constant current , Constant voltage, Floating, Turn-Off 4 state charger for Li-ion battery , open to customize the logical behavior for customer- specified battery pack



Ultra Wide Input Mains range

Strong compatible with ultra with electric environment, stay well with ultra wide range mains of 90V~300V, 40~70Hz ,dramatically reduce battery discharge , prolong battery life.



Best Loading Capability

Up to 0.9 Output Power Factor , 50/60 Hz Automatically adapting, selectable voltage , perfectly match all kind of application



Genset Compatible

Capable of work with wide range of Genset, isolate fluctuation and noise from Genset , provide stable and clean power supply to the user equipment.



High Input power factor

Thanks to digital controlled PFC Technology, >0.99 input power factor, effectively avoid power pollution , save energy expense for customer



Reliable design

Made with strong Glass fiber base (FR4) double side PCB, company with large span component, greatly improve reliability in harsh environment, Well designed ventilation and conformal coating , avoid dust accumulation ,improve resistant to corrosion.



Open to customization

Based on powerful controller and open architecture, the product is able to be customized to match need of integration of automatic system or intelligent supervisory system



Specification

S

Model

1K

1K(S)

2K

2K(S)

3K

3K(S)

Capacity

VA/W

1kVA/800W

2kVA/1.6kW

3kVA/2.4kW

Topology

Double Conversion Online UPS

Phase

Single Phase Input Single Phase Output

Mains Input

Wiring

L/N+PE

Rated Voltage

208/220/230/240VAC

Voltage Range

90~300VAC

Frequency Range

40Hz-70Hz

Input Power Factor

≥0.99

AC Output

Wiring

L/N+PE

Output Voltage

208/220/230/240VAC

Voltage Regulation

±1%

Output Frequency

50/60±4Hz(Sync Mode) / 50/60Hz±0.1%(Free Run)

Waveform

Sine Wave

Distortion (THDV%)

<2%(Linear Load)

<7%(None-Linear Load)

Over load capability

1Min@105%~125%Rated Load 30Sec.125%~150%Rated Load 0.5Sec.>150%Rated Load

Efficiency

AC/AC Mode

88%

89%

90%

DC/AC Mode

86%

87%

88%

Battery & Charger

Rated Battery Voltage

48VDC

Battery Capacity

500WH

External Battery Depends

1000WH

External Battery Depends

1000WH

External Battery Depends

Backup Time

>30mins Full Load

>30mins  Full Load

>15mins Full Load

Charging Current

2.5A

4A

Charging Voltage

56.5V(default for 16cell of LiFePO4 ) / Customerize according to battery request

Charger Behavior & Protection

CC. CV. Floating. Turn-Off 4 states 3 over voltage protection loop, preserve interface for over temperature/over pressure switch off interface

Physical

Chassis Style

RACK / Tower (separated)

Rack Dimension

1K:　438x44(1U)X420mm 1KS: 438x44(1U)X360mm

2K: 438x44(2U)X420mm 2KS:438x44(2U)X360mm

3K: 438x44(2U)X500mm 3KS:438x44(2U)X360mm

Tower Dimension

145×220×390mm

190×318×365mm

HMI

LED DISPLAY

Mains / battery status, Load level, battery level, Operation Mode

LCD DISPLAY

Input Mains Voltage, Frequency, Load level, Operation Mode, Health Status

Standards COMMUNICATION

1. RS232 PORT 2. NMC Card: Support remote monitor the UPS via Smart Phone APP, Web page, PC Monitor Software , Support Server / NAS shutdown

Optional Extension Card

CMC MODBUS Card, USB Card, Relay Card (Needs assembly according to order request before shipping)

Operating Environment Endurance

Temperature range

-10~50oC

Relative Humidity

0-98%(Non-condensing)

Acoustics Noise

<55dB  1 meters



UPS Outlook



Front View



1K(S) Bezel with 2 Button                                                                              2K(S) /S3K(S) Bezel with 2 Button





1K(S) Bezel with 4 Button                                                                                     2K(S) /3K(S) Bezel with 4 Button







                                                                              S1KR(S)-1U





                                    S1KR(S)/S2KR(S)/S3KR(S) /S6KR(S)/S10R(S) RACK UPS



Rear View





                                                             1KS







           2K_HV Rear Panel                                             3K_HV Rear Panel



                                       1KR-1U RACK UPS Rear Panel

                                     1KR(S)-1U RACK UPS Rear Panel



                                          1/2KR(S) RACK UPS Rear Panel



                                                 3K R(S) RACK UPS Rear Panel

Note:

① Battery Capacity and voltage is open to customization

② Dimension might vary for different bezel

③ The socket and terminal configuration on the rear panel may be different for countries or regions according to order

④ More parameter customization,please contact sales representative
